Mazak 14-inch CRT to 12.1-inch LCD Upgrade
Mazak 14-inch color CRT to 12.1-inch TFT-LCD upgrade kit. Compatible with various Mazak Mazatrol systems. Factory direct. Plug-and-play.
$350
USD
✔️ In Stock — 2-Year Warranty
🛒 Buy Now
1
—
—
🔒 Secure checkout via PayPal. Credit/debit cards accepted.
Specifications
| Spec | Original CRT | Kongto LCD |
|---|---|---|
| Technology | 14-inch Color CRT | 12.1-inch TFT-LCD Industrial Panel |
| Resolution | 640x480 | 800x600 |
| Brightness | ~200 cd/m² | 400 cd/m² |
| Lifespan | ~15,000 hrs | 50,000+ hrs |
| Power Supply | AC 110V-220V | AC 110V-220V (compatible) |
| Interface | Mazak 3-row 15-pin (10-pin used) | Mazak 3-row 15-pin (10-pin, direct compatible) |
| Signal Type | RGB analog | RGB analog |
| Safety | High voltage (10-15kV) | Low voltage DC |
| Weight | — | 3.5 kg |
Compatible Systems
- Mazak Mazatrol systems with 14-inch CRT display
Compatible Mazak Models
Mazak 14-inch color CRTs ship on these popular control models — all upgrade to the same 12.1-inch TFT-LCD drop-in replacement:
- Mazak DR5614 CRT to LCD Upgrade
- Mazak CD1472-D1M CRT to LCD Upgrade
- Mazak C5470NS CRT to LCD Upgrade
- Mazak AIQA8DSP40 CRT to LCD Upgrade
Common CRT Failure Symptoms
- Blank screen / no power — Flyback transformer failure, most common
- Dim or unreadable display — CRT phosphor wear after 15,000+ hours
- Flickering or image distortion — Capacitor degradation in sync circuits
- Color shift or missing colors — Aging electron gun or video amplifier
Our LCD module eliminates all CRT-related failure modes permanently.
Frequently Asked Questions
Which Mazak systems is this 14-inch upgrade compatible with?
Compatible with Mazak Mazatrol systems using a 14-inch color CRT, including DR5614, CD1472-D1M, C5470NS, and AIQA8DSP40. Uses the same connector as the original CRT — drop-in replacement, no parameter changes needed.
Installation time and difficulty?
10-15 minutes: power off, remove 4 screws, swap display, reconnect. No soldering.
Image quality vs original CRT?
800×600 resolution, 350-450 cd/m² brightness, 50,000+ hr lifespan. Sharper, no flicker.
Warranty and support?
2-Year Warranty, lifetime support, worldwide shipping.
What Our Customers Say
"CRT was too dim to read. LCD arrived fast, installed in 15 minutes. Crystal clear."
"Perfect plug-and-play. No modifications. Works great. Ordering more."
"After 20+ years our CRT died. This LCD brought our CNC back to life."
Warranty & Service
2-Year Warranty — Lifetime Technical Support — Worldwide Shipping
✉️ [email protected] | 📞 +86-13686889647 | WhatsApp
No CNC parameter changes needed — Plug and play, your machine programs and settings stay intact.
✉️ [email protected] | 📞 +86-13686889647 | WhatsApp
No CNC parameter changes needed — Plug and play, your machine programs and settings stay intact.
Ready to replace your CRT?
$350 — In Stock — Ships within 24 hours
