FANUC A61L-0001-0074 14-inch CRT to 12.1-inch LCD | Color Display Upgrade
FANUC A61L-0001-0074 14-inch color CRT to LCD upgrade — KTV148 12.1-inch TFT LCD module with 400 cd/m² brightness. Plug-and-play, no rewiring. 30-minute installation.
$299
USD
✔️ In Stock — 2-Year Warranty
🛒 Buy Now
1
—
—
🔒 Secure checkout via PayPal. Credit/debit cards accepted.
Specifications
| Spec | Original CRT | Kongto LCD (KTV148) |
|---|---|---|
| Display Technology | 14-inch Color CRT | 12.1-inch Industrial TFT LCD |
| Resolution | 640x480 | 800x600 (640x480 compatible) |
| Brightness | ~200 cd/m2 (decays with age) | 400 cd/m2 (stable) |
| Color Depth | 16/8 colors | 262,144 true colors |
| Lifespan | ~10,000-15,000 hrs | 50,000+ hrs |
| Power Consumption | 35-45W | 7-10W (70% less) |
| Power Input | DC 24V | DC 24V (original PSU) |
| Interface | 20-pin Honda MR-20M | 20-pin Honda (direct compatible) |
| Viewing Angle | CRT (omni-directional) | 160 deg / 140 deg |
| Operating Temp | 0 C to 40 C | -10 C to +60 C |
| Safety | High voltage (10-15kV) | Low voltage DC (safe) |
| Weight | — | 3.5 kg |
Compatible Systems
- FANUC Series 0i-A / 0i-B / 0i-C / 0i-D / 0i-F
- FANUC Series 16i / 18i / 21i / 30i
- FANUC Series 0 / 0-Mate / 0-TMate
- FANUC OM-D / OM-C
- Shenzhen CNC controller systems
- All CNC machines with A61L-0001-0074 14-inch color CRT display
Common CRT Failure Symptoms
- Color distortion / missing colors — CRT phosphor degradation, most common in color CRTs after 10,000+ hours
- Dim display — Electron gun wear reduces brightness to unreadable levels
- Screen flicker / image jitter — Flyback transformer or capacitor degradation
- Focus blur / convergence error — Aging CRT yoke or deflection board
- No display / blank screen — High-voltage failure or CRT heater burnout
Our LCD module eliminates all CRT-related failure modes permanently. 70% lower power, no high voltage, no flicker.
Frequently Asked Questions
Does this work with my CNC machine?
Yes. Uses same connector as original CRT. Drop-in replacement. No parameter changes needed.
Installation time and difficulty?
10-15 minutes: power off, remove screws, swap display, reconnect. No soldering required.
Image quality vs original CRT?
800x600 resolution, higher brightness, 50,000+ hr lifespan. Sharper image, no flicker.
Warranty and support?
2-Year Warranty, lifetime technical support, worldwide shipping from our Shenzhen factory.
What Our Customers Say
"Good communication from seller. Product matched description exactly. Would buy again."
"Replaced the flickering CRT on our milling machine. LCD is crisp and stable."
"CRT was too dim to read. LCD arrived fast, installed in 15 minutes. Crystal clear display."
Warranty & Service
2-Year Warranty — Lifetime Technical Support — Worldwide Shipping
Factory direct from Shenzhen, China. Ships within 24 hours.
Email: [email protected] | WhatsApp: +86-13686889647
No CNC parameter changes needed — Plug and play, your machine programs and settings stay intact.
Factory direct from Shenzhen, China. Ships within 24 hours.
Email: [email protected] | WhatsApp: +86-13686889647
No CNC parameter changes needed — Plug and play, your machine programs and settings stay intact.
Ready to replace your CRT?
$299 — In Stock — Ships within 24 hours
