FANUC Series 0-P A02B-0099-C094 CRT to LCD
The FANUC Series 0-P (also known as the A02B-0099-C094) is a monochrome green-phosphor CRT display assembly used on the classic FANUC 0 series and 0-Mate CNC controls. This 9-inch PBM (Panel Built-in Monitor) unit was standard equipment on countless machine tools from the 1980s through 1990s.
$$299 USD
In Stock — 2-Year Warranty
Specifications
| Spec | Original CRT | Kongto LCD |
|---|---|---|
| Technology | CRT Monochrome/Color | TFT-LCD Industrial Panel |
| Screen Size | 9-inch | 9-inch LED-backlit LCD |
| Resolution | 640x400 / 640x480 | 800x600 |
| Brightness | ~200 cd/m2 | 350-450 cd/m2 |
| Lifespan | ~15,000 hrs | 50,000+ hrs |
| Power | DC 24V | DC 24V (original) |
| Interface | 20-pin Honda MR-20M | 20-pin Honda MR-20M (direct compatible) |
| Safety | High voltage (10-15kV) | Low voltage DC |
Compatible Systems
- FANUC Series 0, 0-Mate, 0-P, 0-T CNC controls
Common CRT Failure Symptoms
- Blank screen / no power — Flyback transformer failure, the most common CRT failure mode
- Dim or unreadable display — CRT phosphor wear after extended operation (15,000+ hours)
- Flickering or image distortion — Capacitor degradation in horizontal/vertical sync circuits
- Color shift or missing colors — Aging electron gun or video amplifier circuit failure
Our LCD module eliminates all CRT-related failure modes permanently. Plug-and-play replacement, no rewiring or parameter changes needed.
Warranty & Service
2-Year Warranty — Lifetime Technical Support — Free Worldwide Shipping
